Super Junction MOSFET (SJ MOSFET) is a novel power device. Employing charge balanced device structure, its on-resistance is significantly low. In the application, SJ MOSFET can reduce the system power loss and increase the power conversion efficiency. At present, it is the most lasting power device in the field of power supply. Internationally, Infineon, Fairchild, ST etc. are the leading companies. Wuxi Tongfang Microelectronics intends to be the most advanced supplier of SJ MOSFET. The products under development include 500V/600V/650V/700V/800V/900V etc. series.

Features of Product:

  • Extremely low loss
  • High reliability
  • Convenient to application

Field of Application
Applicable to PFC, PWM, Adapter , LCD & PDP TV, UPS, Solar Energy etc.

ProductBV(V)ID(A)RDS(on)-typ(Ω)RDS(on)-max(Ω)V(GS)th-min(V)V(GS)th-max(V)Ciss(pF)Qg(nC)Package
TPV70R130A70034.60.110.132.544300115TO-3PN
TPV70R280A70016.80.240.282.54214054TO-3PN
TPP70R280A70016.80.240.282.54214054TO220
TPA70R280A70016.80.240.282.54214054TO-220F
TPP70R480A7009.70.430.482.54134032TO-220
TPA70R480A7009.70.430.482.54134032TO-220F
TPP70R1K1A70050.931.052.5470914TO-220
TPA70R1K1A70050.931.052.5470914TO-220F
TPU70R1K1A70050.931.052.5470914TO-251
TPD70R1K1A70050.931.052.5470914TO-252
TPP70R1K9A7002.71.651.92.544189TO-220
TPA70R1K9A7002.71.651.92.544189TO-220F
TPU70R1K9A7002.71.651.902.544189TO-251
TPD70R1K9A7002.71.651.902.544189TO-252
TPU70R3K1A7001.92.803.102.543006.5TO-251
TPD70R3K1A7001.92.803.102.543006.5TO-252
TPP70R190C700200.170.192.54160541TO-220
TPA70R190C700200.170.192.54160541TO-220F
TPV70R190C700200.170.192.54160541TO-3PN
TPC70R700C70070.640.72.5445010TO-262
TPP70R450C700110.410.452.5470017TO-220
TPA70R450C700110.410.452.5470017TO-220F
TPU70R450C700110.410.452.5470017TO-251
TPD70R450C700110.410.452.5470017TO-252
TPC70R450C700110.410.452.5470017TO-262
TPB70R450C700110.410.452.5470017TO-263
TPP70R700C70070.640.72.5445010TO-220
TPA70R700C70070.640.72.5445010TO-220F
TPU70R700C70070.640.72.5445010TO-251
TPB70R700C70070.640.72.5445010TO-263
TPD70R700C70070.640.72.5445010TO-252
TPP70R950C70060.820.952.544008TO-220
TPA70R950C70060.820.952.544008TO-220F
TPU70R950C70060.820.952.544008TO-251
TPD70R950C70060.820.952.544008TO-252
TPC70R950C70060.820.952.544008TO-262
TPB70R950C70060.820.952.544008TO-263
TPP70R1K4C70041.11.32.543507TO-220
TPA70R1K4C70041.11.32.543507TO-220F
TPU70R1K4C70041.11.32.543507TO-251
TPD70R1K4C70041.11.32.543507TO-252
TPC70R1K4C70041.11.32.543507TO-262
TPB70R1K4C70041.11.32.543507TO-263
TPU70R2K5C70022.22.52.542004TO-251
TPD70R2K5C70022.22.52.542004TO-252
TPU70R2K4C70022.22.52.541703.5TO-252
TPD70R2K4C70022.22.52.541703.5TO-252
