Super Junction MOSFET (SJ MOSFET) is a novel power device. Employing charge balanced device structure, its on-resistance is significantly low. In the application, SJ MOSFET can reduce the system power loss and increase the power conversion efficiency. At present, it is the most lasting power device in the field of power supply. Internationally, Infineon, Fairchild, ST etc. are the leading companies. Wuxi Tongfang Microelectronics intends to be the most advanced supplier of SJ MOSFET. The products under development include 500V/600V/650V/700V/800V/900V etc. series.

Features of Product:

  • Extremely low loss
  • High reliability
  • Convenient to application

Field of Application
Applicable to PFC, PWM, Adapter , LCD & PDP TV, UPS, Solar Energy etc.

ProductV(BR)DSS(V)ID(A)RDS(on)-typ(Ω)RDS(on)-max(Ω)V(GS)th-min(V)V(GS)th-max(V)Ciss(pF)Qg(nC)Package
TPV60R095A60040.50.080.0952.544300115TO-3PN
TPV60R190A600200.170.192.54214054TO-3PN
TPP60R190A600200.170.192.54214054TO-220
TPA60R190A600200.170.192.54214054TO-220F
TPP60R350A60011.50.310.352.54134032TO-220
TPP60R350A60011.50.310.352.54134032TO-220
TPA60R350A60011.50.310.352.54134032TO-220F
TPP60R750A60060.670.752.5470914TO-220
TPA60R750A60060.670.752.5470914TO-220F
TPU60R750A60060.670.752.5470914TO-251
TPD60R750A60060.670.752.5470914TO-252
TPP60R1K4A6003.21.241.392.544189TO-220
TPA60R1K4A6003.21.241.392.544189TO-220F
TPU60R1K4A6003.21.241.392.544189TO-251
TPD60R1K4A6003.21.241.392.544189TO-252
TPU60R2K2A6002.31.932.162.543006.5TO-251
TPD60R2K2A6002.31.932.162.543006.5TO-252
TPU60R190B600200.160.192.54144070TO-220F
TPD60R190B600200.160.192.54144070TO-220F
TPP60R650B60070.580.652.5436025TO-220
TPA60R650B60070.580.652.5436025TO-220F
TPU60R650B60070.580.652.5436025TO-220
TPD60R650B60070.580.652.5436025TO-220F
TPP60R850B60050.770.852.5432015TO-220
TPA60R850B60050.770.852.5432015TO-220F
TPU60R850B60050.770.852.5432015TO-251
TPD60R850B60050.770.852.5432015TO-252
TPP60R150C600200.130.152.54160541TO-220
TPA60R150C6002000.130.152.54160541TO-220F
TPV60R150C600200.130.152.54160541TO-3PN
TPP60R350C600110.310.352.5470017TO-220
TPA60R350C600110.310.352.5470017TO-220F
TPU60R350C600110.310.352.5470017TO-251
TPD60R350C600110.310.352.5470017TO-252
TPC60R350C600110.310.352.5470017TO-262
TPB60R350C600110.310.352.5470017TO-263
TPP60R580C60070.50.582.5445010TO-220
TPA60R580C60070.50.582.5445010TO-220F
TPU60R580C60070.50.582.5445010TO-251
TPD60R580C60070.500.582.5445010TO-252
TPC60R580C60070.50.582.5445010TO-262
TPB60R580C60070.50.582.5445010TO-263
TPP60R700C60060.620.72.544008TO-220
TPA60R700C60060.620.72.544008TO-220F
TPU60R700C60060.620.72.544008TO-251
TPD60R700C60060.620.72.544008TO-252
TPC60R700C60060.620.72.544008TO-262
TPB60R700C60060.620.72.544008TO-263
TPP60R840C60040.80.852.543507TO-220
TPA60R840C60040.80.852.543507TO-220F
TPU60R840C60040.80.852.543507TO-251
TPD60R840C60040.80.852.543507TO-252
TPC60R840C60040.80.852.543507TO-262
TPB60R840C60040.80.852.543507TO-263
TPP60R950C60040.80.952.543507TO-220
TPA60R950C60040.80.952.543507TO-220F
TPU60R950C60040.80.952.543507TO-251
TPD60R950C60040.80.952.543507TO-252
TPC60R950C60040.80.952.543507TO-262
TPB60R950C60040.80.952.543507TO-263
TPU60R1K7C60021.51.72.542004TO-251
TPD60R1K7C60021.51.72.542004TO-252
TPU60R2K3C60021.82.12.542004TO-251
TPD60R2K3C60021.82.12.542004TO-252
TPU60R2K1C60021.82.12.541703.5TO-251
TPD60R2K1C60021.82.12.541703.5TO-252
